Product Gallery
Características
| Model | GDF-25C30M | GDF-25C80M | GBR-4C700M |
| Technical Data | |||
| Type | -25 Mobile Cooler | -25 Mobile Cooler | 4°C Mobile Cooler |
| Cabinet Type | Chest | Chest | Chest |
| Climate Class | N | N | N |
| Cooling Type | Forced Air Cooling | Forced Air Cooling | Forced Air Cooling |
| Defrost Mode | Manual | Manual | No frost with heated glass door |
| Refrigerant | R134a | R134a | R134a |
| Dimensions | |||
| Shelves/Basket | Basket around Evaporator | Blood Baskets | |
| Capacity(L) | 30 | 80 | 700 |
| Internal Size(W*D*H)mm | 364×253×352.5 | 547×378×369.5 | 939×973×863 |
| External Size(W*D*H)mm | 615×370×471.5 | 937×565×580.5 | 1090×1129.5×1080 |
| Packing Size(W*D*H)mm | 690*430*540 | 990*630*630 | 1140*1190*1150 |
| Net/Gross Weight(kg) | 22/26 | 47/55 | 162/185 |
| Performance | |||
| Cooling performance(℃) | -25/4/22 | -25/4/22 | 4℃/22℃ |
| Temperature Range(℃) | -25/4/22 | -25/4/22 | 4℃/22℃ |
| Noise (db) | 45 | 46 | 50 |
| Electrical Data | |||
| Sensor | NTC | NTC | NTC |
| Temperature Controller | Microprocessor | Microprocessor | Microprocessor |
| Display | Digital Display | Digital Display | Digital Display |
| Current | DC 6.5A | ADC 8A | DC12V、DC24V、AC220V |
| Power Supply | 220/50Hz、DC12V/24V | 220/50Hz、DC12V/24V | DC12V/14A、DC24V/7A、AC220V/1.5A |
| Power(W) | 80W | 100W | 160W |
| Material | |||
| Chamber | PE | PE | PE |
| Outer | PE | PE | PE |
| Insulation | PURF | PURF | PURF |
| Alarms | |||
| High and Low Temp. | Y | Y | Y |
| Thermostat Failure | Y | Y | Y |
| Power Failure | Y | Y | Y |
| Sensor Error | Y | Y | Y |
| Accessories | |||
| Basket | Basket around Evaporator | Blood Baskets | |
| Foot | / | / | PE foot |
| Power Failure Backup for Alarm | 8h | 8h | 8h |
| Remote Alarm Port | Optional | Optional | Optional |
| Temperature Recorder | Optional | Optional | Optional |
Descripción
| PURPOSE | To store and transport blood, serum, plasma, vaccine, reagents and special medicines in medical industry. Also used as medicines pass box for epidemic prevention station, blood bank, health center, CDC, animal husbandry bureau, army and logistics service, espress company, pharmaceutical factory, genetic engineering. |
| USER FRIENDLY DESIGN | • The whole roll structure prevents collision damage. • Multilayer stacking. |
| SECURITY GUARANTEE | • Functional alarm system with audible and visible • Constantly alarm after power off • Keyboard lockable • Remote control |
| FEATURES | • Multi-function with 3 ranges of inner temperature: 2℃~8℃ used as pharmacy refrigerator, -10℃ or -25℃ used as deep freezer, 22±2℃ used an incubator • Multiple voltage used as AC220V or DC12V/24V (Only for blood transporation) power supply of cigarette lighter• Combined with forced air cooling system and direct cooling system • Whole roll PE structure |
