Product Gallery
CHARACTERISTICS
| Model | GPR-S320Pro | GPR-S410Pro |
| Size | ||
| Capacity(L/cu.ft) | 320\11.12 | 410\14.69 |
| Standard Shelf/drawer | Anti-corrosion Painted Steel Shelves*6/Basket*1 | |
| Exterior Size(W*D*H)(mm) | 640*580*1920 | 780*580*1920 |
| Interior Size(W*D*H)(mm) | 540*425*1380 | 685*425*1380 |
| Package Size(W*D*H)(mm) | 740*655*2040 | 875*650*2065 |
| NT./GT.(kg) | 95/110 | 115/128 |
| CBM | 0.99 | 11.75 |
| Performance | ||
| Temperature Range | 2-8℃ | |
| Temperature Accuracy | 0.1℃ | |
| Temperature Vibration | ±3℃ | |
| Climate/ Ambient Temperature | 10-32℃ | |
| Noise(db) | 50 | |
| Refrigeration System | ||
| Refrigerant | R134a | |
| Cooling | Forced Air Cooling System | |
| Defrost | Auto | |
| Compressor Brand/Qty | CHINA BRAND/1 | |
| Insulation | PURF | |
| Control System | ||
| Temperature Controller | Microprocessor | |
| Sensor | NTC | |
| Display | Digital display | |
| Power | ||
| Voltage Frequency(V/Hz) | 220V±10%, 50Hz/60Hz； 110V/60Hz | |
| Power Consumption(kWh/24h) | 1.91 | 2.66 |
| Power(W) | 220W | 230W |
| Current(A) | 1.15 | 1.18 |
| Construction | ||
| Inside Material | Anti-corrosion painted steel | |
| Outside Material | Anti-corrosion painted steel | |
| Outer Door Glass | Heating glass door with automatic rebound | |
| Foot or Caster | Standard | |
| Audible and Visual Alarms | ||
| High/Low Temperature | Standard | |
| Power failure | Standard | |
| Thermostat failure | Standard | |
| Door ajar | Standard | |
| Accessories | ||
| Lamp | LED light | |
| Power Failure Backup System (Aarm) | 72h | |
| Door Lock | Door lock | |
| Test Hole QTY/Diameter | 1/25MM | |
| USB Port | Standard | |
| Temperature Recorder | Optional | |
| Remote Alarm Port | Optional | |
| RS232/485/ Port | Optional | |
DESCRIPTION
Application:
The pharmacy refrigerators are suitable for refrigeration storage solution drug stores,pharmaceutical companies,hospitals,epidemic prevention centers and clinics.
Superior Performance:
* USB for parameters output
* Heated anti-frog glass door
* LED lamp, more safe and durable
* Test-hole for temperature monitoring
* Cool fast with high efficiency fan
* Glycerin sensor box accurately simulate chamber temperature
* Optimized forced-air distribution system
* Optimized space with adjustable shelves and basket
| Alarm | Alarm Triggering Condition | |||||
| High Temperature | Temperature reaches the warm alarm limit | |||||
| Low Temperature | Temperature reaches the low alarm limit | |||||
| Power Failure | Equipment loses power | |||||
| Door Ajar | Door open period exceeds 5 minutes | |||||
